Configured for climates where incoming water temperatures are in the 60 deg. to 70 deg. F. range. Self-modulating flow-sensor technology regulates the amount of energy required to heat the water needed. Digital temperature display showing the outlet water temperature setting. Uses (2) 9 kW standard Emerson electric heating elements with brass tops to prevent electrolysis. Copper heat exchanger. Automatic resettable thermostat. (2) 40 DP breakers required. 75A draw. Required wire: 2 sets 8 AWG. Pipe fitting: 3/4" NPT. Energy factor: 0.998. UL and CSA certified. Dimensions: 14" x 17.75" x 4.25". Weight: 9 lb. Lifetime warranty.
Capacity | 3.5 gpm |
Type | Tankless |
Fuel Type | Electric |
Wattage | 18000W |
Voltage | 240V |
Height | 17-3/4 In. |
Width | 14 In. |
Depth | 4-1/4 In. |
Family Size | 3 |
For Mobile Home Use | No |
Uniform Energy Factor | 0.998 |
Warranty | Lifetime |
