Single-sided positive turning insert, 80° rhomboid with 7° clearance, inscribed circle diameter of 3/8", 5/32" thick, 1/64" nose radius and indexing accuracy according to ISO-tolerance class- M, chip-breaker RF, in grade T7335, a MT-CVD coated functionally graded WC-Co carbide, for fine to heavy machining
- Product Name ISO: CCMT 09T304E-RF:T7335
- Ordering Code ANSI: CCMT 32.51-RF:T7335
- EDP Number: 6756026
- Coating: T7335
| Product Measurement Standard | Metric |
| Depth of Cut Maximum (Mm.) | 4 |
| Corner Radius (Mm.) | 0.4 |
| Fixing Hole Diameter (Mm.) | 4.4 |
| Inscribing Circle Dia. (Mm.) | 9.525 |
| Insert Thickness (Mm.) | 3.97 |
| Max Depth of Cut (In.) | 0.157 |
| Insert Geometry | Positive |
| Coating | T7335 |
