JTJ-5ST, 5 Ton Hydraulic Toe Jack
- Dual purpose jack designed for low or high clearances increases versatility
- Overload Protection valve prevents lifting loads past maximum capacity
- Electric welded bases and cylinders virtually eliminating leaks for proven reliability
- High or low extreme temperature fluxuations do not affect jack performance increasing durability
- Heat treated piston resists corrosion
- Spring assisted return and over-travel protection increases tool life
- Lifting, pushing, spreading, bending, pressing or straightening capabilities for multi-function use
- Pump handle included
- Complies with ANSI/ASME B30.1 Standards
| Base Dimensions (LxW)(In.) | 10-5/8 x 7-1/4 |
| Load Capacity (Tons) | 5 |
| Rated Toe Capacity (Tons) | 5 |
| Rated Head Capacity (Tons) | 6 |
| Toe Minimum Height (In.) | 1-1/16 |
| Toe Maximum Height (In.) | 5-3/4 |
| Toe Lift (In.) | 4-11/16 |
| Head Minimum Height (In.) | 11-1/2 |
| Head Maximum Height (In.) | 11-1/2 |
| Toe Size (LxW)(In.) | 2-1/2 x 3 |
| Weight (Lbs.) | 48 |
