Single-sided milling insert ADKT 1505 with chip-breakers, 85° parallelogram for a maximum depth of cut of .5118", with .0315" corner radius, an indexing accuracy according to ISO-tolerance class-K and M geometry with rounded cutting edges, MM8218 MT-CVD coated WC-Co carbide for machining of steel
- Product Name ISO: ADKT 1505PDTR-M:MM8218
- Ordering Code ANSI: ADKT 1505PDTR-M:MM8218
- EDP Number: RSD211251
- Coating: MM8218
- Material Application Priority Usage: K - Cast Iron (castings of iron and carbon alloys with > 2% carbon content), P - Steel and cast steel (steels with alloy content = 10% and a hardness of < 45HRC)
| Product Measurement Standard | Metric |
| Depth of Cut Maximum (Mm.) | 13 |
| Corner Radius (Mm.) | 0.8 |
| Fixing Hole Diameter (Mm.) | 4.4 |
| Insert Thickness (Mm.) | 5.6 |
| Insert Width (Mm.) | 9.525 |
| Max Depth of Cut (In.) | 0.512 |
| Coating | MM8218 |
